Full product description
Basic Parameters
| Brand | JFMIX |
| Model | ZL-932-30 |
| Date of issue | 2023 |
| Engine | Yunnei 4100 diesel |
| Number of cylinders | 4 |
| Manufacturer country | China |
| Operating weight | 5000 kg |
| load capacity | 1500 kg |
| Wheel base | 2240 mm |
| Length/width/height (mm) | 6500*1850*2700 |
| Digging radius | 3700 mm |
| Transmission | Automatic built-in |
| Front bucket volume | 0,8 cubic meters |
| Rear bucket volume | 0,2 cubic meters |
| Digging depth | 2000 mm |
| Working angle of the excavator | 270° |
| Power (hp/kW) | 65/87 |
| Electrical system | 24V |
| Tires | 20,5-16 |
| Brake system | hydropneumatic |
| Maximum speed (km/h) | 30 |
| Angle of rotation | 33° |
| Front ridge emptying height | 3200 mm |
| Rear skate emptying height | 3100 mm |
| Heating/air conditioning | + |
